Billboards 1 & 2, from Billboard series





The Wisconsin Truck Stop is a multi-program space

consisting of a diner, a gas station, and a motel.

The first goal of the project was to create a structure

that was one and also many. The second goal

was to have the total mass contain multiple

personalities. A personality matrix was designed to

determine the true intentions of each program.

wisconsinmatrixone

Personality & Program Matrix


Screen Shot 2017-10-02 at 3.27.46 PM.png



A Form + "Style" Matrix was created to determine which

faces best expressed each personality. Each elevation

would then be used as the outline for an anamorphic

projection from the four cardinal directions.



A series of wire models was produced to articulate

which direction individual line segments should travel

after producing the projected facade.



Screen Shot 2017-10-02 at 3.29.00 PM.jpg
INDEDECA


SECTIONS

FINAL SINGLE SEXSHUNS [Converted]2.jpg

Section Drawing of the Gas Station & the Diner

FIRST FINUL BOARD.jpg

Section Drawing of the Gas Station, the Diner,

& some restrooms
